METAL SPACERS FOR EVERY APPLICATION
To ensure perfect spacing between two pieces of reinforcement mesh and ideal concrete coverage, Multifil has a wide range of spacers from 20mm to 400mm height for compressive strengths up to 450kg/m² (when placed correctly). Multifil also offers spacers with a DBV certificate. This guarantees quality in all conditions.
TRIANGULAR SPACERS - TYPE A
Metal triangle spacers are known for their robustness and versatility. These spacers offer an excellent balance between load-bearing capacity and stability, ideal for light to heavy reinforcement mesh when used in floors and walls.
COMPACT AND SMALLER PACKAGING
STRONG AND STABLE
LIGHTWEIGHT AND EASY TO USE
SMOOTH EDGE
Type A
NORMAL EXECUTION
This spacer, available in heights from 50 to 200 mm, is suitable for loading of up to 350 kg/m²
Type A-DBV
Heavy Duty
Suitable for heavier loading (over 450 kg/m²).
DBV-certified
ZIGZAG SPACERS - TYPE ZZ
These smooth edged zig-zag spacers are patented for their unique shape, packaging and manufacturing process. They are particularly sturdy and stable, making them useful for large surface areas.
COMPACT PACKAGING BUT IN LARGER QUANTITIES THAN TYPE A
STRONG AND STABLE
ECONOMIC
SMOOTH EDGE
Type ZZ
NORMAL EXECUTION
This spacer, available in heights from 50 to 200 mm, is suitable for loading of up to 350 kg/m²
Type ZZ-DBV
Heavy Duty
Suitable for heavier loading (over 450 kg/m²).
DBV-certified
TRAPEZOIDAL SPACERS - TYPE N
The trapezoidal smooth-edged N spacers are a cross between the traditional type A spacer and the zig-zag spacer. Its unique shape makes it very stable, convenient to use and suitable for all applications both in horizontal and vertical use.
COMPACT PACKAGING
ECONOMIC
SMOOTH EDGE
STRONG AND STABLE
Type N
This spacer, available in heights from 50 to 150 mm, is suitable for loading of up to 350 kg/m²
